Conductor: Solid Bare copper (1 x AWG24)
Insulation : HDPE
- Min. Avg. Thickness: 0.178 mm;
- Min. Thickness: 0.153 mm
Color Code:
- Pair 1: Blue & White/Blue;
- Pair 2: Orange & White/Orange
- Pair 3: Green & White/Green;
- Pair 4: Brown & White/Brown
Jacket:
- LDPE
- Min. Avg. Thickness: 0.585 mm;
- Min. Thickness: 0.458 mm
- Approximate O.D.: 5.2 mm +/- 0.3mm
Electric Requirements: (Cable length: 100M)
- Characteristic Impedance(Zo): 85～115Ω (1～100 MHz)
- Other Requirements: (dB/100M)
- DC. Resistance Capacitance Unbalance: 5％
- Pair-to-Ground Capacitance Unbalance: 330 pF/100M Max
- Conductor Resistance: 9.38Ω/ 100M 20℃ Max
- Mutual Capacitance: 5.6 nF/m Max
- Spark Test: 2.5KV
