AJAX
Ajax EN54 FireProtect Smoke black
Κωδικός παραγγελίας: 29481EAN: 4823114069277
- Frequency Bands:866.0–866.5 MHz / 868.0–868.6 MHz / 868.7–869.2 MHz / 905.0–926.5 MHz / 915.85–926.5 MHz / 921.0–922.0 MHz
- Maximum effective radiated power (ERP):up to 20 mW / Automatic power control to reduce power consumption and radio interference.
- Radio signal modulation:GFSK
- Radio communication range:up to 1,700 m / Between the device and control and indicating equipment (CIE) or a range extender in an open space.
- Encrypted communication:All stored and transmitted data is protected by block encryption featuring a dynamic key.
- Όλα τα χαρακτηριστικά
138,00 €με ΦΠΑ
Αποστολή σε 2-4 εργάσιμες
Δωρεάν παραλαβή από το κατάστημα
Περιγραφή
- EN54 FireProtect (Smoke) Jeweller is a wireless addressable point smoke detector. The device complies with EN 54 requirements and ensures smoke detection if signs of smoke are present.
- EN54 FireProtect (Smoke) Jeweller operates as part of an Ajax system and communicates with control and indicating equipment (CIE) via secure Jeweller radio protocol. The communication range with the CIE is up to 1,700 m in an open space.
Χαρακτηριστικά
- Frequency Bands
- 866.0–866.5 MHz / 868.0–868.6 MHz / 868.7–869.2 MHz / 905.0–926.5 MHz / 915.85–926.5 MHz / 921.0–922.0 MHz
- Maximum effective radiated power (ERP)
- up to 20 mW / Automatic power control to reduce power consumption and radio interference.
- Radio signal modulation
- GFSK
- Radio communication range
- up to 1,700 m / Between the device and control and indicating equipment (CIE) or a range extender in an open space.
- Encrypted communication
- All stored and transmitted data is protected by block encryption featuring a dynamic key.
- Frequency Hopping
- To prevent radio interference and jamming.
- Sensitive element
- dual-spectrum optical sensor / Detects smoke based on the size of particles in the air.
- False alarm protection
- The device does not respond to water vapor.
- Patented smoke chamber
- Protects the smoke sensor from dust, dirt, and insects.
- Alarm Type
- acoustic
- Sound volume
- up to 95 dB at a distance of 1 m / Adjusted by a PRO or user with admin rights in an Ajax app.
- Sound pattern
- 32 tones
- Sound synchronization
- An audible alarm is automatically synchronized on all devices with a sounder connected to the same CIE.
- Alarm annunciation test
- An audible alarm check to ensure the fire alarm is clearly audible on the premises.
- Lock for SmartBracket
- to secure the device on the SmartBracket mounting panel / When locked, the lock secures the device and prevents it from being removed without a special tool.
- Protection against spoofing
- Device authentication
- Connection loss detection
- after 36 s / Detection time depends on Jeweller settings.
- Battery
- 2 × CR123A / Pre-installed.
- Tool-free battery replacement
- To replace the batteries, open the lids of the battery compartments.
- Reverse polarity protection
- Prevents device damage if the batteries are put in incorrectly.
- Recommended battery type
- Huiderui CR123A; 3 V; 1,600 mAh, LiMnO₂
- Calculated battery life
- up to 5 years
- Dimensions
- 124 × 124 × 48 mm
- Weight
- 295 g
- Operating temperature range
- from 0 °C to +50 °C
- Operating Humidity
- Up to 80%
- Protection class
- IP21C
- Flammability rating
- UL 94 V-0
- Color
- Black
- Revision
- 1
