AJAX Keypad Black

AJAX Keypad Black

• Wireless touch keypad is used for arming/disarming of Ajax security system. It is mounted in the room near the entrance door to provide quick access to the keypad
• The device activates the full security mode by pressing one button
• If the robber tries to enter the code, a hidden alarm signal can be sent to the Central Monitoring Station
• The keypad is blocked automatically if the incorrect code is entered too many times
• Authentication to prevent forgery
• Jamming detection and communication channels encryption
• Tampering alarm

• Sensor type : Capacitive
• Tamper protection : Yes
• Protection against passcode guessing : Yes
• Frequency band 868.0 – 868.6 MHz or 868.7 – 869.2 MHz
• Maximum RF output power : Up to 20 mW
• Modulation of the radio signal : GFSK
• Radio signal range : Up to 1,700 m (if there are no obstacles
• Power supply : 4 x AAA batteries
• Power supply voltage : 3 V
• Battery life : Up to 2 years
• Operating temperature range : From -10°C to +40°C
• Operating humidity : Up to 75%
• Overall dimensions : 150 ? 103 ? 14 mm
• Weight : 197 g
• Certification : Security Grade 2, Environmental Class II in conformity with the requirements of EN 50131
