Reolink POE NVR 36-port without POE without HDD NVS36

Χαρακτηριστικά

Hardware

N5MB01

Video Out

1 HDMI, 1 VGA

Audio Ports

1 audio-in channel, RCA; 1 audio-out channel, RCA

USB Ports

Front panel: 1 x USB 2.0; back panel: 1 x USB 2.0, 1x USB 3.0

Ethernet Ports

• 4 x RJ-45, 10/100/1000 Mbps self-adaptive (for IP cameras) / • 1 x RJ-45, 10/100/1000 Mbps self-adaptive (for LAN/WAN) / • No PoE Port

Alarm

In: 8 channels; Out: 4 channels

IP Camera Input

Supports up to 36 channels of IPC access; each channel up to 16MP input

Video Output

• HDMI: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768 / • VGA: 1920x1080, 1280x1024, 1280x720, 1024x768

Two-Way Audio

Built-in audio in & out ports

Audio In

Via cameras with mic; via built-in 1 channel

Audio Out

Via bulit-in 1 channel

Video Compression

H.265, H.264

Live View / Playback Resolution

7680x2160, 4608x1728, 4512x2512, 4096x3072, 3840x2160, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p, 720p (supports only 1-channel playback if you view it in 8MP or higher resolution.)

Synchronous Playback

1-4 channels

Supported Modes

Person/vehicle event recording; motion-triggered recording; / 24/7 recording

Internal HDD

3 SATA ports for 3 HDDs (optional)

External HDD

No

Max. Capacity

48TB (max. 16TB HDD for each SATA)

Network Protocols

HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP

Browsers Supported

Edge, Firefox, Chrome, Safari

OS Supported

PC: Windows, Mac OS; Smartphone: iOS, Android

Max. User Access

20 users (1 admin account & 19 user accounts); up to 12 simultaneous video streams (10 substreams & 2 mainstreams)

Power Supply

DC 12V/5.4A

Power consumption

<10W（without HDD）

Working Environment

Temperature: -10°C to +45°C (14°F~113°F); / Humidity: 10% to 90%

Dimensions

330 x 48 x 310mm

Weight

2.26kg (without HDD)
