Z790 PRO RS MOTHERBOARD DDR5 ATX LGA1700 (GEN12) ASROCK

Z790 PRO RS MOTHERBOARD DDR5 ATX LGA1700 (GEN12) ASROCK

• Number of Usb 2.0 Ports: 4

• USB 3.2 Gen 1 ( 3.1 Gen 1) Number of Type A ports: 2

• USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 1

• USB 3.2 Gen 2 (3.1 Gen 2)Number of Type-C ports: 1

• Number of Ethernet LAN ports (RJ-45): 1

• Number of HDMI ports: 1

• Number of PS/2 connections: 1

• Number of DisplayPort connections: 1

• Displayport version: 1.4

• Headphone outputs: 1

• Microphone input: Yes

• Number of USB 2.0 Interfaces: 2

• USB 3.2 Gen 1 (3.1 Gen 1) ports: 2

• USB 3.2 Gen 2 (3.1 Gen 2) ports: 1

• SATA III Connectors: 8th

• Front panel Audio connector: Yes

• ATX Power connector (24-pin): Yes

• CPU FAN Connector: Yes

• TPM Connector: Yes

• Thunderbolt headers: 1

• RGB LED header: 1

• Motherboard from Factor: ATX

• Motherboard Chipset family: Intel

• Motherboard Chipset: Intel Z790

• Audio Channels: 7.1 channels

• Audio Chip: Realtek ALC897

• Supports: Windows 10x 64, Windows 11×64

• BIOS Type: UEFI AMI

• BIOS Memory size: 128Mbit

• Supported Memory: DDR4 SDRAM

• Number of memory slots: 4

• RAM memory maximum: 128GB

• Memory type: DIMM

• Memory channels: Dual Channel

• Without ECC: Yes

• Unbuffered Memory: Yes

• PCI Express x1 (Gen 3.x) connectors: 2

• PCI Express x16 slots(Gen 4.x): 1

• PCI Express x16 Slots(Gen 5.x): 1

• Number of M.2 (M) Slots: 1

• Wireless internet access: NO

• Built-in Ethernet port: yes

• Ethernet interfaces type: 2.5 Gigabit Ethernet

• LAN controller: Dragon RTL8125BG

• Processor socket: LGA 1700

• Compatible processors: Intel Core i5, Intel Core i7, intel core i9

• Maximum number of SMP processors: 1

• Supported storage drive interfaces: M.2, SATA III

• Supported storage drives: HDD & SDD

• RAID Support: Yes

• RAID Levels: 0,1,5,10
