Dahua Alarm Wireless Repeater ARA43-W2(868)
- Connects up to 32 peripherals
- Two-way RF communication
- LED indicator displays device status
- Supports manual and auto paring, extending RF distance for your security system
- Auto switches from dual antennas to reduce blind areas
- Cloud update and auto recovery of update failure
- Battery backs device working for over 35 hours when external power supply fails
Input/Output
- Wireless Zone : 32 × wireless peripherals
Port
- Storage Battery : Built-in lithium battery
- Indicator Light : 1 that indicates pairing and working
- Power Switch : 1 × power switch
Function
- Pairing Mode : Auto/Manual
- Tamper Alarm : Yes
- Remote Update : Cloud update
- Power Failure Protection for Configured Parameters : Yes
- Disconnection Detection of External Power Supply : Yes
- Low Battery Alarm : Yes
- Search : Signal strength detection
Wireless
- Carrier Frequency : 868.0 MHz–868.6 MHz
- Communication Distance : Up to 1,600 m in an open space
- Communication Mechanism : Two-way
- Encryption Mode : AES128
- Frequency Hopping : Yes
General
- Power Supply : 12 VDC, 1.5 A
- Battery Life : Battery standby time: 35 h
- Operating environment : –10 °C to +55 °C (indoor)
- Operating Humidity : 10%–90% (RH)
- Product Dimensions : 163.0 mm × 163.0 mm × 32.0 mm
- Packaging Dimensions : 219.0 mm × 187.0 mm × 91.0 mm
- Installation : Wall mount, Desktop
- Net Weight : 0.32 kg
- Gross Weight : 0.74 kg
- Certifications : CE
- Casing : PC+ABS
