HYPONTECH
HYPONTECH OnGrid Inverter HPS-5000D Single Phase 5KW
Κωδικός παραγγελίας: 25876
- Max PV Power (W):7000
- Max Input Voltage (V):600
- MPPT Voltage Range (V):80-520
- Start Up Voltage (V):70 V
- Rated Input Voltage (V):360
- Όλα τα χαρακτηριστικά
499,00 €749,00 €με ΦΠΑ
Κερδίζετε 250,00 € (33%)
Αποστολή σε 2-4 εργάσιμες
Δωρεάν παραλαβή από το κατάστημα
Περιγραφή
HPS-5000D Inverter 1 Phase 4KW
- Peak Efficiency 98%
- Max DC Overload 40%
- Aluminum Alloy casting
- MES-FCT-CRM Ifrastructure
- Easy Installation and Service
Χαρακτηριστικά
- Max PV Power (W)
- 7000
- Max Input Voltage (V)
- 600
- MPPT Voltage Range (V)
- 80-520
- Start Up Voltage (V)
- 70 V
- Rated Input Voltage (V)
- 360
- Max Input Current (A)
- 13
- Max Short Circuit Current (A)
- 20
- No. of MPPTs
- 2
- No. of Strings Per MPPT
- 1
- Rated Power (W)
- 5000
- Max. Apparent Power (VA)
- 5000
- Rated Grid Volatege (Vac)
- 220/230/240
- Grid Connection
- L-N-PE
- Rated Grid Frequency (Hz)
- 50/60
- Max Output current (A)
- 23
- Power Factor
- 0.8 ind - 0.8 cap
- Max Efficiency
- 97.9%
- Euro Efficiency
- 97.4%
- MPPT Efficiency
- 99.9%
- Anti Islanding Proctection
- Intergrated
- PV String Onput Reverse Polarity Protection
- Intergrated
- Insulation Resistance Detection
- Intergrated
- Resudula Current Monitoring Unit
- Intergrated
- Output Over Current Protection
- Intergrated
- Output Short Circuit Protection
- Intergrated
- Over Voltage Protection
- II(DC), III(AC)
- Surge Protection
- DC Optional , AC Type II
- Dimensions (W*H*D)(mm)
- 395*328*154
- Weght (Kg)
- 9.8
- Noise Emission (Typical) dB(A)
- 20
- User interface
- LCD&LED
- PV connection Type
- MC4
- AC Conection Type
- Plug in connection
- Communication
- RS485/WIFI/4G/LAN
- Colling Method
- Natural Cooling
- Operating Ambient Temperature (C)
- -25 to +60
- Relative Humidity (%)
- 0 -100
- Max Operating Altitude (m)
- 3000
- Protection class
- IP65
- Climatic Category (IEC 60721-3-4)
- 4K4H
- Topology
- Tranformerless
- Night Consumption (W)
- <1
