AJAX SURVEILLANCE NVR 16ch HDMI 80Mbps 1080p HAC
Order code: 29525EAN: 4823114076626
- Video Input:16 channels
- Recording resolution:8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
- HDMI output resolution:1920 × 1080 / 1600 × 1200 / 1280 × 1024 / 1280 × 720 px
- Live View / Playback Resolution:8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 720p / D1 / VGA / CIF
- Format:H.265 / H.264 / JetSparrow
- All specifications
€693.00incl. VAT
Ships in 2-4 working days
Free pickup from our shop
Description
- Guiding video to top-tier security
- Efficient video monitoring for any site
- Video monitoring — exactly how it's meant to be
- Complete awareness with a customizable video wall
- Smooth archive navigation
- Rapid and encrypted data transfer
- Easy integration through ONVIF and RTSP
- Instant event-to-video alarm verification
- Built-in motion detection
- Verified evidence with no effort
- Discover future-proof hardware
- HDMI output / two USB ports / AC/DC power connectors
- LED indicator
- Quiet fan for active cooling
- Hard drive latch
- Rule your video surveillance
- Hassle-free installation and setup
- Established security experience
Specifications
- Video Input
- 16 channels
- Recording resolution
- 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
- HDMI output resolution
- 1920 × 1080 / 1600 × 1200 / 1280 × 1024 / 1280 × 720 px
- Live View / Playback Resolution
- 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 720p / D1 / VGA / CIF
- Format
- H.265 / H.264 / JetSparrow
- Capability
- 1 × channel at 8MP , 3 × channel at 5MP / 4 × channel at 4MP / 4 × channel at 1080p / 10 × channel at 720p / 16 × channel at 1024 × 576 px
- Live view window division
- templates : 1 / 4 / 9 / 16 / 5+1 / 7+1 views / custom : up to 10×10 views
- Synchronous Playback
- 16 channels
- Motion Detection
- Ajax camera : 16 channels / NVR : 16 channels
- AI object detection
- Ajax camera : 16 channels
- HDD
- 1 × SATA : supports hard drive with up to 16 TB capacity (3.5” form factor) <strong>***HDD is not included</strong>
- Network
- 1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)
- USB
- rear panel : 1 × USB 2.0 (Type-A) / side panel: 1 × USB 2.0 (Type-A) (To connect a keyboard, mouse, or a USB flash drive)
- Bandwidth
- incoming : up to 80 Mbps / outgoing : up to 40 Mbps
- Protocol
- HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / SNMP / RTSP / UDP / DHCP / DNS / DDNS
- Interoperability
- ONVIF
- Supported devices
- Ajax cameras / IP cameras using ONVIF (Profile S/T) or RTSP
