Dahua VD 2-wire Wi-Fi Hybrid KIT KTX01

Order code: 27039

Main Processor:Embedded Processor
Button Type:Mechanical
Camera:1/2.8" 2 MP CMOS HDR Camera
Field of View:H: 110°; V: 60°
WDR:DWDR
All specifications

€582.00incl. VAT

Out of stock

Description

2-wire Wi-Fi Hybrid Indoor Monitor:

7" TFT capacitive touch screen.
Offers video intercom that communicates with VTOs through half-duplex, and the app through full-duplex.
Supports recording videos and capturing snapshots. (SD card is required).
6-channel alarm input and 1-channel alarm output.
The app can be used to receive calls and alarm notifications.
Connects to HDCVI camera.

2-wire Hybrid Villa Door Station:

Aluminum alloy front panel.
Auto IR illumination.
Video messages can be left for unanswered calls. (SD card is required for VTH).
Features nameplate and DWDR.
Supports local lock and second lock.
Offers anti-tampering alarm.
IP65 and IK07 rated.

Specifications

Main Processor: Embedded Processor
Button Type: Mechanical
Camera: 1/2.8" 2 MP CMOS HDR Camera
Field of View: H: 110°; V: 60°
WDR: DWDR
Noise Reduction: 3D NR
Video Resolution: P: 960 (H) × 576 (V) , N: 960 (H) × 480 (V)
Video Frame Rate: P: 25 fps , N: 30 fps
Light Compensation: Auto IR
Day/Night: Auto(ICR)/Color/B/W
Audio Input: 1
Audio Output: Built-in speaker
Audio Mode: Two-way audio with VTO (half–duplex);Two-way audio with app (full–duplex)
Unlock Mode: Remote unlock
Leave Videos: Yes (SD card needed)
Casing Material: PC + ABS
RS-485: 1
Alarm Output: 1
Power Output: 1 (12 V, 200 mA)
Exit Button: 1
Door Status Detection: 1
Lock Control: 1
Alarm: Tamper Alarm : Yes
Appearance Color: White
Power Supply: 48 VDC
Installation: Surface Mount
Certifications: CE; FCC
Product Dimensions: P 65.2 mm × 46.2 mm × 23.2 mm (2.57" × 1.82" × 0.91")
Protection: IP65 , IK07
Operating Temperature: –10 °C to +55°C (14 °F to +131 °F)
Operating Humidity: 10%–95% (RH)
Operating Altitude: 0 m–3000 m (0 ft – 4265.09 ft)
Power consumption: 3.5 W
Gross weight: 0.13 kg (0.29 lb)
Storage Temperature: –40 °C to +70°C (–40 °F to +158 °F)
Storage Humidity: 95% (RH), non-condensing
Operating System: Embedded operating system
Network Protocol: IPv4; UDP; DNS; TCP
Screen Type: Capacitive Touchscreen
Display Screen: 7" TFT
Screen Resolution: 1024 (H) × 600 (V)
Audio Compression: G.711a; G.711u; PCM
Audio Enhancement: Echo suppression/digital noise reduction
Audio Bit Rate: 16 kHz; 16 bit
DND Mode: Do not disturb period can be set; Do not disturb mode can be set.
Number of Extensions: 5
Wi-Fi: YES
Wireless Standard: IEEE802.11b/802.11g/802.11n
Wireless Frequency Range: 2.4 GHz
Max Transmission Power: ≤20 dBm@2,400–2,483.5 MHz
Storage: Micro SD card (up to 64 GB)
Alarm Input: 6
Door Bell: Yes (use the alarm input port)
Accessory: Included: Line termination terminal
