Dahua CAT5e Cable CCA 305m Orange DH-PFM922I-5EUN-C
Dahua CAT5e Cable CCA 305m Orange DH-PFM922I-5EUN-C

Dahua CAT5e Cable CCA 305m Orange DH-PFM922I-5EUN-C

€69.00 €89.00
  • 305m/carton UTP CA5e CCA, power over Ethernet, compatible with one cable
  • Manufacturing excellence
  • Customized PVC outer sheath, equipped with certain flame retardancy
Specification
  • FR-PVC (ROHS compliant)
  • 5.1 mm ± 0.3 mm
  • 24 AWG
  • 0.5 mm
  • Orange
  • 500D
  • 14.5 Ω/100 m (14.5 Ω/328.08 ft)
  • 5000 MΩ/km
  • 2% (pair intra), 4% (pairs inter)
  • 5.6 nF/100 m (5.6 nF/328.08 ft)
  • No breakdown with 1kV DC for 1 min
  • Sheath ≥13.5 MPa, insulation ≥16 MPa
  • Sheath ≥150%, insulation ≥300%
  • >8 times of the outer cable diameter
  • ≥8%
  • ≤5%
  • No migration
  • ≥12.5 MPa, ≥100%
  • No cracking after the test
  • No cracking after the test
  • –20 °C to +60 °C (–4 °F to +140 °F)
  • 0 °C to +50 °C (32 °F to 122 °F)
  • –10 °C to +40 °C (14 °F to 104 °F), <60% (RH)
  • Comply with IEC 60332-2-2
  • 305.0 m ± 2 m (1000.66 ft ± 6.56 ft)
  • 6.2 kg ± 0.5 kg (13.67 lb ± 1.1 lb)
  • 7.0 kg ± 0.5 kg (15.43 lb ± 1.1 lb)
  • 364 mm × 216 mm × 364 mm (14.33" × 8.5" × 14.33") (L × W × H)
  • 447 mm × 382 mm × 386 mm (17.6" × 15.04" × 15.2") (L × W × H)
  • 305.0 m (1000.66 ft) per carton, and 2 cartons per transport package
  • Q/DXJ 067-2019
